470W BSW 3in1 moving / CMY
Input Voltage: AC100-250V 50/60Hz, 700VA at 230V 50Hz
Automatic power supply switching
Light Source: 1* OSRAM SIRIUS HRI 470W lamp
Color Temperature: 7,800 K
Life: 1,500hrs
Luminoux flux: 23,000 lm
COLOR SYSTEM:
CMY color system based on 3 gradually fading color wheels
13 color filters on three wheels
2 CTO filters (3,200K and 2,500K) + 1 CTB filter
EFFECTS SECTION:
2 gobo wheels:
wheel with 7 HQ dichroic, indexable and interchangeable rotating gobos (25.9mm).
interchangeable and variable rotating wheel with 13+1 fixed
metal gobos (including 6 beam reducers).
Prism wheel:One rotated 8 prism and one 16-facet linear prism
CONTROL:
DMX512, master-slave and sound activated or auto operation
30 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Display: Graphic LCD Display
DMX signal connection: 3 pole XLR input and output
Angle: Linear motorized ZOOM 3.8°-53°
RDM available (Remote Device Management)
PAN = 540° - TILT = 244°
IP20
