Input Voltage:
90-260V, 50-60 Hz
Lamp source: OSRAM
10R 260W (MSD Platinum 17R 350W
Optional)
Power Consumption:
450W
Protocol: USITT DMX-512
Channels: 16/20
DMX channels
Pan
movement:540°(16bit)
Tilt
movement:210°(16bit)
Advanced moving
system:
Scan position
memory, auto reposition after unexpected movement
three-phase motor,
fast, stable and quiet, auto X-Y repositioning
Beam Angle: 2 °
Waterproof rating: IP 65
Strobe: Mechanical
strobe and can adjust speed, support Macro function of strobe
Bubble function: remote
DMX controller control point bubble, bubble, and display panel can be set to
open bright bubble function
Lens optical
system: Electrical focus, Double thick
stepping motor
Color wheel: One
color wheel, imported high temperature resistant color film, 14 colors +open,
rainbow effect
Fixed gobo wheel: One
fixed gobo wheel, 17 fixed Gobos + Open
Prism: One rotated
8 prism and one 16-facet linear prism, Macro Function, (Can be customized with
Colorful Honeycomb Prism)
Radiating System: The
machine is made of die-cast aluminum design material, with very fast heat
dissipation, built-in dehumidification and heat dissipation patented technology
devices, with waterproof and dustproof functions. Flicker-free operation
Control Mode: DMX512,
master-slave and auto operation
Dimming:0-100% electric linear dimmer
Controls: High-end touch LCD display with 4 control
buttons
LCD display
switch-off automatically after 60 seconds
Frost :fine wash
effect
Built-in program: built-in
multiple effect programs, can achieve a single beam of white left and right
slow pendulum, to achieve a single color change around the slow pendulum and
multi-beam color around the slow pendulum
Power supply: The
use of Chinese famous brand power supply, as well as imported lighting
fixtures, the whole lamp power supply system is more stable, the function runs
more smoothly.
Light
Size:340*340*600mm
N.W:19kg
